Veterinary Instruments Custom Made Orthopedic Kit
- Custom designed orthopedic system kit
- Includes drill bits, bone screws, screw drivers, bone plates, and drill guides
- Implants made of stainless steel or titanium
- Various sizes available for different procedures
- Option to choose from different instrument cases
- SKU
- OD-00253
- Brand
- Orthoprovet
- Availability
- In stock
- ✓ Warranty included
- ✓ Worldwide shipping
Veterinary Instruments Custom Made Orthopedic Kit
Fully customizable orthopedic system kit designed for veterinary surgical applications. Includes drill bits, bone screws, screw drivers, bone plates, and drill guides. All implants available in stainless steel or titanium with multiple sizes for diverse procedures.
Clinical overview
This custom-made orthopedic system kit is engineered for veterinary surgeons requiring a comprehensive, modular solution for fracture fixation and bone plate procedures. The kit combines precision-engineered drill bits, cortical and cancellous bone screws, specialized screw drivers, and load-bearing bone plates—all available in stainless steel or titanium to meet your clinical and material preferences.
The system is fully customizable, allowing you to select the exact combination of instruments and implants needed for your surgical cases. Five different instrument case options ensure compatibility with your existing autoclave systems, while maintaining optimal organization and sterility throughout your surgical workflow.
Key features & surgeon benefits
Comprehensive implant range
- Drill bits from 1.0 mm to 4.0 mm (Jacob Chuck)
- Cortical screws 1.5–3.5 mm diameter, lengths 6–50 mm
- Cancellous screws 4.0–6.5 mm diameter, lengths 10–50 mm
- Bone plates 1.5–6.5 mm with 3–20 hole options
Optimized surgical efficiency
- Quick-coupling screw drivers with fiber handles
- Neutral and load drill guides for all sizes
- Organized tray systems for rapid instrument access
- Five case sizes to fit your autoclave specifications
Cost-effective customization
- Build only the kit you need—no unnecessary components
- Durable stainless steel or premium titanium construction
- Reduced inventory complexity with modular design
- Competitive pricing for veterinary practices
Tailored to your needs
- Select specific drill bit sizes and quantities
- Choose cortical or cancellous screw configurations
- Mix and match bone plate sizes and hole counts
- Five instrument case options for autoclave compatibility
Technical specifications
| Indications | Veterinary orthopedic fracture fixation, bone plate fixation, and internal fixation procedures |
|---|---|
| Sizes / range | Drill bits: 1.0, 1.3, 1.5, 1.7, 2.0, 2.5, 2.7, 3.2, 3.5, 4.0 mm; Cortical screws: 1.5–3.5 mm diameter; Cancellous screws: 4.0–6.5 mm diameter; Bone plates: 1.5–6.5 mm; Five case size options |
| Material | Stainless steel or titanium (implants and instruments) |
| Sterilisation | Autoclavable; instrument cases designed to fit standard veterinary autoclaves |
| Packaging | Five different instrument case sizes available; custom tray organization |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Drill bits (Jacob Chuck) | 1.0, 1.3, 1.5, 1.7, 2.0, 2.5, 2.7, 3.2, 3.5, 4.0 mm | As selected |
| Cortical bone screws (hex head, self-tapping) | 1.5 mm (6–20 mm), 2.0 mm (8–30 mm), 2.7 mm (10–30 mm), 3.5 mm (10–50 mm) | As selected |
| Cancellous bone screws (fully threaded) | 4.0 mm (12–50 mm), 6.5 mm (10–30 mm) | As selected |
| Screw drivers | Quick coupling with fiber handle, all sizes | As selected |
| Bone plates | 1.5 mm (3–12 hole), 2.0 mm (3–12 hole), 2.7 mm (3–12 hole), 3.5 mm (3–12 hole), 4.5 mm (5–20 hole), 6.5 mm (5–20 hole) | As selected |
| Drill guides | Neutral and load drill guides, all sizes | As selected |
| Instrument case | Five different sizes available; custom selection based on autoclave compatibility | 1 |
Get in touch for pricing & availability
Contact our sales team to discuss your custom kit requirements, material preferences, and case specifications. We'll work with you to design the ideal orthopedic system for your veterinary practice.
Email: [email protected]
Available on request
Configuration, paperwork & clinical fit
The full spec + documentation pack for this device ships ahead of purchase on request. A sales engineer responds within one business day.
Configuration sheet
Specifications, accessories & clinical fit
Sizes and dimensions, material and finish, compatible instruments and screw references, what ships in the set, lead time and warranty — all in one specification sheet, sent within one business day.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Need configuration help, certificates, or volume pricing?
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
