Veterinary Instruments Medium Kit 2.7/3.5/4.0mm
- High-quality orthopedic implants and instruments
- Made from the same material used in human medicine
- Includes 10 additional instruments compared to other sets
- All stainless steel material with aluminum case
- Dimensions: 15.5" x 9.5" x 4" (L x W x H)
- System includes various drill bits, bone taps, other instruments, bone plates, and bone screws
- SKU
- 9AB32192EF2C
- Brand
- Orthoprovet
- Availability
- In stock
- ✓ Warranty included
- ✓ Worldwide shipping
Veterinary Instruments Medium Kit 2.7/3.5/4.0mm
A comprehensive surgical instrument set designed for veterinary orthopedic procedures. Manufactured to human-grade medical standards with stainless steel construction, this kit includes 10 additional instruments compared to standard sets, providing surgeons with complete coverage for fracture fixation and bone plating applications.
Clinical overview
The Veterinary Instruments Medium Kit represents a professional-grade solution for orthopedic surgical procedures in veterinary practice. Manufactured to the same exacting standards as human medical instruments, this comprehensive set delivers the precision, durability, and reliability required for complex fracture fixation and bone plating applications. The kit's expanded instrument complement—10 additional items beyond standard offerings—ensures surgeons have immediate access to specialized tools for reduction, plate bending, screw extraction, and depth measurement without requiring supplementary purchases.
Housed in a robust aluminum case with secure locking mechanism, the kit maintains instrument organization and sterility throughout the surgical workflow. All stainless steel construction ensures corrosion resistance and compatibility with standard autoclave sterilization protocols, while the included screw rack and individually packaged bone plates facilitate inventory management and surgical planning.
Key features & surgeon benefits
Complete Surgical Range
- Drill bits in 2.0mm, 2.5mm, and 3.2mm sizes
- Bone taps for 2.7mm, 3.5mm, and 4.0mm applications
- Dual-purpose drill guides and tap sleeves for workflow efficiency
Optimized Surgical Efficiency
- 10 additional instruments reduce need for external tool sourcing
- Specialized reduction forceps and plate benders for precise positioning
- Broken screw extractor and depth gauge for intraoperative problem-solving
Value-Driven Investment
- Comprehensive kit eliminates need for multiple supplementary purchases
- Human-grade material quality ensures long instrument lifespan
- Competitive pricing with 2-year manufacturer warranty
Flexible Configuration Options
- Optional titanium implants available for specific applications
- Custom kit configurations available upon request
- Modular design allows selective instrument replacement
Technical specifications
| Indications | Veterinary orthopedic fracture fixation, bone plating, surgical reduction |
|---|---|
| Sizes / range | 2.0mm, 2.5mm, 2.7mm, 3.2mm, 3.5mm, 4.0mm |
| Material | Stainless steel instruments; aluminum case with secure locking cover |
| Sterilisation | Autoclavable; compatible with standard steam sterilization |
| Packaging | Aluminum case with organized instrument trays and screw rack; dimensions 15.5" × 9.5" × 4" (L × W × H) |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Drill Bit 2.0mm | Precision drill bit for initial hole creation | 2 |
| Drill Bit 2.5mm | Precision drill bit for intermediate sizing | 2 |
| Drill Bit 3.2mm | Precision drill bit for larger hole preparation | 2 |
| Neutral Drill Guide 2.0mm | Neutral positioning guide for 2.0mm applications | 1 |
| Neutral Drill Guide 2.5mm | Neutral positioning guide for 2.5mm applications | 1 |
| Neutral Drill Guide 3.2mm | Neutral positioning guide for 3.2mm applications | 1 |
| Load Drill Guide 2.0mm | Load-bearing drill guide for 2.0mm applications | 1 |
| Load Drill Guide 2.5mm | Load-bearing drill guide for 2.5mm applications | 1 |
| Load Drill Guide 3.2mm | Load-bearing drill guide for 3.2mm applications | 1 |
| Combined Drill Guide & Tap Sleeve 2.0mm/2.7mm | Dual-purpose guide for 2.0mm drilling and 2.7mm tapping | 1 |
| Combined Drill Guide & Tap Sleeve 2.5mm/3.5mm | Dual-purpose guide for 2.5mm drilling and 3.5mm tapping | 1 |
| Combined Drill Guide & Tap Sleeve 3.2mm/4.0mm | Dual-purpose guide for 3.2mm drilling and 4.0mm tapping | 1 |
| Bone Tap 2.7mm | Thread-cutting tap for 2.7mm screw holes | 1 |
| Bone Tap 3.5mm | Thread-cutting tap for 3.5mm screw holes | 1 |
| Bone Tap 4.0mm | Thread-cutting tap for 4.0mm screw holes | 1 |
| Depth Gauge | Precision measurement tool for screw length determination | 1 |
| Hex Head Screwdriver 2.5mm with Screw Holding Sleeve | Screwdriver with retention mechanism for secure screw placement | 1 |
| Small Screw Holding Forceps | Precision forceps for handling small screws | 1 |
| Large Plate Benders (Pair) | Specialized benders for contouring larger bone plates | 1 |
| Small Plate Benders (Pair) | Specialized benders for contouring smaller bone plates | 1 |
| Periosteal Elevator Round Head | Soft tissue retraction and periosteal separation tool | 1 |
| Periosteal Elevator Flat Head | Flat-blade periosteal separation and elevation tool | 1 |
| Broken Screw Extractor | Specialized tool for removal of fractured screws | 1 |
| Reduction Forceps | General-purpose reduction and holding forceps | 1 |
| Reduction Forceps with Point | Pointed reduction forceps for precise anatomical alignment | 1 |
| Self-Centering Forceps | Automatic centering mechanism for plate positioning | 2 |
| Small Countersink | Countersinking tool for smaller screw heads | 1 |
| Large Countersink | Countersinking tool for larger screw heads | 1 |
| Bone Plate 2.7mm | Stainless steel compression plate for 2.7mm screws | 2 |
| Bone Plate 3.5/4.0mm | Stainless steel compression plate for 3.5mm and 4.0mm screws | 2 |
| Cortical Self-Tapping Hex Head Screw 2.7mm | Cortical screw for dense bone fixation | 10 |
| Cortical Self-Tapping Hex Head Screw 3.5mm | Cortical screw for dense bone fixation | 10 |
| Cancellous Self-Tapping Hex Head Screw 4.0mm | Cancellous screw for metaphyseal and cancellous bone fixation | 10 |
Get in touch for pricing & availability
Contact our sales team to request a detailed quote, discuss custom configurations, or arrange a product demonstration. We offer fast delivery and comprehensive technical support for all veterinary orthopedic instruments.
Email: [email protected]
Available on request
Configuration, paperwork & clinical fit
The full spec + documentation pack for this device ships ahead of purchase on request. A sales engineer responds within one business day.
Configuration sheet
Specifications, accessories & clinical fit
Sizes and dimensions, material and finish, compatible instruments and screw references, what ships in the set, lead time and warranty — all in one specification sheet, sent within one business day.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Need configuration help, certificates, or volume pricing?
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
